“wet” oxygen measurement. The definition of oxygen measurement on a “dry” basis is based on the assumption that the moisture content in a flue stream is removed before the oxygen content is measured. Portable oxygen analyzers provide a “dry” oxygen measurement. There will be a difference in the two methods of measuring oxygen.
Oxygen measurement in the percentage range to trace measurement in the range of ppm and ppb can be achieved within a second without disadvantages to the sensory installation. Oxygen meter GSM-touch The hand-held Oxygen Meter GSM-touch is a state-of-the art measuring instrument controlled by a touch pad. Oxygen diffuses through the membrane and is reduced at the cathode by the voltage. This process produces a current flow, which is detected by the meter and is proportional to the partial pressure of oxygen. Since oxygen is 'consumed' the sample needs to be stirred to ensure accurate readings. Gas-phase oxygen electrode systems allow the measurement of oxygen evolution or uptake within a sealed sample chamber. The sample chamber is designed to accommodate 10cm 2 leaf discs which are cut using a special leaf disc cutter. However, any sample type such as root sections, lichens, mosses, conifer needles or small seeds may be used.
GSM-touchHand-held oxygen measuring device with touch pad
GSM V6Extremely versatile oxygen measuring device
GSMCombination measuring device GSM
Z15Oxygen supply modul
U15 DigitalOxygen measuring and control device
This instrument which can be used in a versatile manner covers the whole range of oxygen measurement in heat treating and in laboratory.
Zirconium oxide as measuring principle fulfils all demands which are expected of a modern trace analyser.
Used in a mobile or stationary manner, the GSM-V6 is a product of up-to-date technology.
Oxygen measurement in the percentage range to trace measurement in the range of ppm and ppb can be achieved within a second without disadvantages to the sensory installation.
Oxygen meter GSM-touch
The hand-held Oxygen Meter GSM-touch is a state-of-the art measuring instrument controlled by a touch pad.
This oxygen meter is integrated in an elegant aluminium housing. The display's 24mm character height makes it very easy to read the measurements.
A graphical display with freely programable axes continually shows the current value and the selected history.
The measured values can be saved onto a flash drive through the oxygen meter‘s USB interface or sent on via Ethernet.
Parameterising outputs, alarms and histogram on the touch pad is easy and self-explanatory.
Specifications oxygen meter GSM-touch
Measuring principle | Zirconium oxide |
Display | - Oxygen in %, ppm, bar |
Measuring range | 100% to 10E-33 bar |
Sample gas pump | integrated |
Power supply | 110 - 230 Volt, 50/60 Hz |
Dimensions, Weight | ca. 315 x 210 x 75 mm plus carrying handle, ca 3.5 kg |
Analogue output 1 Analogue output 2 | Linear, programable 0/4 - 20 mA Logarithmical or additional function, programable 0/4 - 20 mA |
Digital output 1 Digital output 2 | Limit values, alarms (3 floating relays) Ethernet, USB |
Portable oxygen measuring and control instrument GSM-V6
This extremely versatile instrument covers the entire range of oxygen measuring in heat treatments and in the laboratory.
Use of zirconium oxide as the measuring principle meets all the expectations placed on a modern trace analyser. The GSM-V6 is a leading-edge technological product, whether used as a mobile or an immobile device.
Oxygen Measurement
Consequently, the numerical an time-based graphical display of oxygen, lambda an dew-point will exactly represent process parameters.
Technical data GSM-V6
Display | LCD, 64x128 pixel |
Representation | - Oxygen in %, ppm, bar - Calculated dew point of 90 to –90 degrees |
Exit | 0/4-20 mA scalable 2 relays without potential for control device or limiting value |
Dimensions | About 160 x 260 x 260 mm plus handle, about 4 kg |
Power supply network | 230 Volt, 50/60 Hz |
Measuring range | 100% to 10E-33 bar oxygen |
Measuring principle | Ziconium oxide |
Measuring gas transport | Incorporated controllable gas pump |
| Measuring gas supply | 3mm Swagelok |
Combination measuring instrument GSM
This GSM type installation measuring and control instrument visualizes signals of oxygen sensors by its LCD matrix display.
Thus the numerical and time-dependent graphical representation of oxygen, lambda, C-level and dew point depicts method parameters in an exact manner.
The incorporated control device and individually adjustable limiting values allow the control of oxidative method conditions in a reproducible way.
Technical data GSM
| Display | LCD, 64x128 pixel |
| Representation | - Oxygen in %, ppm, bar |
| Exit | 0/4-20 mA scalable 2 relays without potential for control device or limiting value |
Dimensions | 96 x 96 x 180 mm |
| Power supply network | 115/230 volt, 50/60 Hz |
| Measuring range | 100% to 10E-33 bar oxygen |
Combinable with sensor |
|
Technical data Z15
- Aluminium housing 120 x 120 mm, 110 mm height for screw assemblage
- Supply modul and impedance converter for sensor type A15
- Supply 230 VE
Oxygen measuring and control device U15-Digital
The U15-DIGITAL series measuring module includes the following functions:
- Measures the oxygen partial pressure in connection with a separate series A or C
sensor - Output of measured value 0 to 20 mA, switchable to 4 to 20 mA
- Generation of alarms
The module is parameterized after the installation, if necessary, and will operate permanently with these settings.
Oxygen Measurement Device
Technical Data U15-Digital
Blood Oxygen Measurement
Measuring range | 100 % to 10-31 bar O2 |
Ambient temperature | 0 to 45 degrees Celsius |
Measuring accuracy | +/- 0.3 mV of the sensor e.m.f. |
Dimensions | ca. 150 x 180 x 90 mm (HxWxD) |
Weight | ca. 1.5 kg |
Supply voltage | 230 VAC, 24 VDC |
Output | Acc. to sensor type, ca. 100 VA max. |
1 (optionally 2) analog output(s) | 0/4 – 20 mA configurable, floating |
2 Relay outputs | configurable for alarms, 1A, 24 V (ohmic) |
